Upper clip

PROSTILTadvance 2.0

The principle of PROSTILTadvance 2.0 is quickly explained. The 2.40 m long basic pro-files, which are available in two colours, can be extended as required using the PROS-TILTadvance 2.0 longitudinal connector. The PROSTILTadvance 2.0 cross connector or the PROSTILTadvance 2.0 variable connector is used for the cross connection. You can position and lock the cross connector at any point* in the groove of the base profile in order to be able to connect a base profile there as well. This principle can be conti-nuously extended in length and width. Finally, the supporting structure is placed on the PROSTILTadvance 2.0 adjustable feet, which can build up the terrace at heights between 11 and 370 mm. The possible difference in height allows levels to be set down and steps to be formed. The high load-bearing capacity of the PROSTILTadvance 2.0 supporting structure also enables large spans and thus significantly fewer support points than with conventional substructures.
